Features

· Bariatric, latex free, therapeutic foam mattress provides pressure redistribution and shear/friction reduction
· Full width top layer is high-resilient, high-density die-cut foam for pressure redistribution and maximum support
· High-density foam bottom layer provides support and stability for the bariatric patient
· Patented LuraQuilt foam heel section offloads pressure from vulnerable heels
· Removable premium, multi-stretch cover is fluid resistant, low shear and vapor permeable helping protect the skin from friction and moisture
· Meets flammability standard CFR 1632 and CFR 1633

Product Manuals + Documentation

bariatric-foam-mattress

42″ and 48″ foam mattresses

X Close

Features

· Active mattress replacement system provides both alternating pressure and low air loss to optimize pressure redistribution, shear/friction reduction, and microclimate control
· Designed to prevent, treat and heal pressure ulcers in the home or long term care setting
· Control unit offers 10 minute cycles when alternating and can also be used in static mode
· Adjustable patient weight settings allow for optimal immersion and patient comfort & compliance
· Audio and Visual alarm alerts when air pressure is low
· System includes 17 individual air cells over a 3″ foam base for power outage protection
· Pillow feature provides head stability & comfort
· 5″ deep air cells are easily removed for convenient servicing
· Removable quilted Nylon cover is fluid resistant, low shear and vapor permeable helping protect the skin from friction and moisture
· CPR valve allows for rapid deflation
· Tubing quickly and easily disconnects with EZ Lock/Quick Release design

Specifications

· Control Unit Power: 110 VAC \ 60 Hz
· Control Unit Airflow: 8 LPM
· Control Unit Cycle Time: 10 Min.
· Control Unit Type: Compressor
· Control Unit Alarms: Visual / Audible
· Mattress Cover Material: Fluid-Resistant Nylon
· Weight Capacity: 350 lbs.

Product Manuals + Documentation

drive-apm-manual

drive-apm-system_14530

APM (Alternating Pressure Mattress) System w/ LAL technology 36″

X Close

Product Description

Our True Low Air Loss System with Pulsation offers an extraordinary therapeutic mattress system for the prevention and treatment of pressure ulcers. The Powerloft Pro 900 pump produces 1180 liters of air flow per minute offering a cool and dry sleeping surface. There are 10 Adjustable Comfort Settings allows pressure to be customized by patient’s weight. The Auto-Firm feature allows for a 1 minute fill rate and the exclusive Pulsate mode reduces the air flow every 30 seconds to 50% of the comfort setting. This feature will intermittently reduce pressure and increase blood flow. The internal pressure control sensor continuously monitors surface pressure for optimal pressure redistribution. This low air loss mattress system is an excellent choice for use in the Homecare, Long Term Care, and Acute Care Markets. Included is a 2″ convoluted foam base in case of power outage and features a CPR valve that allows for rapid deflation of mattress system. The static function can suspend the pulsate mode. This mattress has Visible and audible alarms with Alarm Mute feature.

Features

· offers an extraordinary therapeutic mattress system for the prevention and treatment of pressure ulcers.
· produces 1180 liters of air flow per minute offering a cool and dry sleeping surface.
· The 10 Adjustable Comfort Settings allows pressure to be customized by patient’s weight.
· The Auto-Firm feature allows for a 1 minute fill rate.
· The exclusive Pulsate mode reduces the air flow every 30 seconds to 50% of the comfort setting. This feature will intermittently reduce pressure and increase blood flow.
· The internal pressure control sensor continuously monitors surface pressure for optimal pressure redistribution.
· 2″ convoluted foam base in case of power outage.
· CPR feature allows for rapid deflation of mattress system
· Static function can suspend the pulsate mode.
· Visible and audible alarms with Alarm Mute feature.
· CPR valve allows for rapid deflation.

Product Manuals + Documentation

drive-lal-pressure_prev-12-ls9000

True LAL (Low Air Loss Mattress) System (36″ 42” 48”)

X Close

Features

· Combination therapy active system incorporates the functions of lateral rotation and low air loss to assist with pulmonary blood flow and mucosal drainage as well as providing microclimate control to keep the patient cool and dry
· Designed to prevent, treat and heal pressure ulcers in the home or long term care setting
· Control unit offers 10 comfort levels, 10,20, 30 & 60 minute adjustable turning cycles and maximum turn angle adjustments
· Turning modes include combinations of ¼, ½, ¾, and adjustable turning positions up to 40 degrees with left, right, both or none (static) directions
· Audio and Visual alarm alerts when air pressure is low
· Advanced Clinical and Care Giver
· Auto-Firm, auto-recovery, microprocessing feedback, lock-out and more!
· Unique split air cells provide customizable turn time and rotation angles for patient comfort and satisfaction
· Solonoid valves prevent air loss and provide power outage protection
· Removable quilted Nylon cover is fluid resistant, low shear and vapor permeable helping protect the skin from friction and moisture
· CPR valve allows for rapid deflation
· Weight capacity: 500 lbs

Product Manuals + Documentation

drive-turn-q-manual

turn-q-mattress

Turn Q Mattress (Lateral Rotation)

X Close

Features

· Best in class gel overlay optimizes pressure redistribution
· 15 gel bladders cover entire patient contact area for the prevention and treatment of pressure ulcers
· Full length “head-to-toe” gel bladders minimize “bottoming out” and “pitting”
· New convoluted foam topper vastly improves patient comfort and air circulation
· 4 elastic corner straps secure overlay to mattress
· Urethane coated nylon cover is water resistant and vapor permeable
· Vinyl base is stain resistant and waterproof
· Bladders contain an aqueous non-toxic gel and polystyrene beads to minimize gel migration

Product Manuals + Documentation

gel-mattress-manual

gel-mattress

Gel Mattress Overlay (36″ 42”)

X Close

Product Description

Featuring special zoned layers of high density foam for aid in pressure relief on areas susceptible to pressure ulcers and soft head and heel sections for ultimate comfort, this dual-layered mattress has the comfort and technology that users need.

Features

· Nylon top cover and tri-laminate vinyl bottom for ease in cleaning and durability
· Two layer, high density foam designed to help prevent pressure ulcers
· Aids in providing uniform weight distribution for pressure ulcer prevention
· Raised sides provide additional support

Specifications

Material: Foam
Dimensions: 80″ L x 36″ W x 9″ H
Product Weight Capacity: 300 lb.

Product Manuals + Documentation

fall-prevention-mattress

Fall Prevention/Scoop Mattress

X Close

Features

· Quiet pump alternately inflates and deflates 130 individual bubble air cells
· 4 LPM (liters per minute) pump produces consistent air flow and pressure over a 5 minute cycle time and is available fixed or variable
· Variable pressure setting on pump allows for individualized comfort increasing patient compliance
· Durable, heavy gauge, premium vinyl bubble pad provides superior therapeutic treatment and is available with or without end flaps

Product Manuals + Documentation

app-overlay-manual

med-aire-alternating-pressure-pump-and-pad-system

APP Bed Overlay

X Close

Features

· The Defined Perimeter Mattress Cover creates a raised rail, defined perimeter for enhanced fall prevention, without using patient restraints
· Open in mid-section for safe and easy patient egress and ingress
· Built-in medium density foam bolsters safely and comfortably define edges of bed for patient and prevent falling
· Easy-to-install and secure
· Breathable Nylon makes this a truly universal cover, compatible with both foam and powered air surfaces

Specifications

· Fits Mattresses 34-43″ (W) X 80″ (L) X 6″-10″ (H)
· Foam Sections: 5½” (W) x 29½” (L) x 4″ (H)
· Shipping Weight: 5 lbs.
· Cover Material: Nylon
· Foam Density: Medium
· Warranty: Limited 1 Year

Product Manuals + Documentation

bolster-cover

Mattress Bolsters
